DSL (Digital Subscriber Line) is a technology for bringing high-bandwidth information to homes and small businesses over ordinary copper telephone lines. xDSL refers to different variations of DSL, such as ADSL, HDSL, and RADSL. Assuming your home or small business is close enough to a telephone company central office that offers DSL service, you may be able to receive data at rates up to 6.1 megabits (millions of bits) per second (of a theoretical 8.448 megabits per second), enabling continuous transmission of motion video, audio, and even 3-D effects. More typically, individual connections will provide from 1.544 Mbps to 512 Kbps downstream and about 128 Kbps upstream. A DSL line can carry both data and voice signals and the data part of the line is continuously connected.

Types of DSL

ADSL

The variation called ADSL (Asymmetric Digital Subscriber Line) is the form of DSL that will become most familiar to home and small business users. ADSL is called "asymmetric" because most of its two-way or duplex bandwidth is devoted to the downstream direction, sending data to the user. Only a small portion of bandwidth is available for upstream or user-interaction messages. However, most Internet and especially graphics- or multi-media intensive Web data need lots of downstream bandwidth, but user requests and responses are small and require little upstream bandwidth. Using ADSL, up to 6.1 megabits per second of data can be sent downstream and up to 640 Kbps upstream. The high downstream bandwidth means that your telephone line will be able to bring motion video, audio, and 3-D images to your computer or hooked-in TV set. In addition, a small portion of the downstream bandwidth can be devoted to voice rather data, and you can hold phone conversations without requiring a separate line. Unlike a similar service over your cable TV line, using ADSL, you won't be competing for bandwidth with neighbors in your area. In many cases, your existing telephone lines will work with ADSL. In some areas, they may need upgrading.

G.SHDSL

Also known as G.991.2, G.SHDSL is an international standard for symmetric DSL developed by the ITU. G.SHDSL provides for sending and receiving high-speed symmetrical data streams over a single pair of copper wires at rates between 192Kbps and 2.31 Mbps.

HDSL

HDSL (High bit-rate Digital Subscriber Line), one of the earliest forms of DSL, is used for wideband digital transmission within a corporate site and between the telephone company and a customer. The main characteristic of HDSL is that it is symmetrical: an equal amount of bandwidth is available in both directions. HDSL can carry as much on a single wire of twisted-pair cable as can be carried on an E1 line (up to 2.048 Mbps) in Pakistan.

SDSL

SDSL (Symmetric DSL) uses a single twisted-pair line carrying 2.048 Mbps each direction on a duplex line. It's symmetric because the data rate is the same in both directions.

VDSL

VDSL (Very high data rate DSL) is a developing technology that promises much higher data rates over relatively short distances (between 51 and 55 Mbps over lines up to 1,000 feet or 300 meters in length). It's envisioned that VDSL may emerge somewhat after ADSL is widely deployed and co-exist with it.
